350~520MHz Wilkinson splitter HY-WS0305-2/3/4W

Frequency Band (MHz)

350-520MHz

Input Ports

2-way

3-way

4-way

Split Loss(dB)

3.0

4.8

6.0

Insertion Loss(dB)

≦0.3

≦0.5

≦0.5

Isolation(dB)

          ≧20

            ≧18

            ≧18

VSWR

         ≦1.30

           ≦1.30

          ≦1.30

Average Power(W)

50

RF Connector

N-female

Working Temperature

-35~+65

Relative Humidity

5%-95%

Application

Indoor

Color

Black-plated

Weight(kg)

0.27

0.35

0.47
